Audison Coaxial Voce 200W Peak Power 165 mm 4 Ohm Speaker - AVX6.5



Online Only

Literature

Coaxial | 200 W Peak Power | 165 mm | 4 ohm

The AV X5 and AV X6.5 coax speakers are the evolution of the woofer from the same line, thanks to the introduction of an excellent 1 Tetolon dome tweeter. The Orientable High Frequency Tuning technology also provides the ability to optimize dispersion in high range to achieve the best performance in the listening point, while the woofer used the aerodynamic basket, the Triple Wave surround profile in butyl rubber, the CCAW voice coil wound on double layer and exclusive Cotton-fibre pressed paper cone with Light Damping treatment. The coaxial element is perfected by a refined on-wire dedicated crossover, supplied with the product.

FEATURES

  • The profile of the aerodynamic basket’s spokes along with the open-air design ensure drastic reduction of back-wave reflections.
  • The exclusive Butyl rubber Triple Wave surround profile provides full linearity as well as reliable performance under extreme conditions.
  • Extremely lightweight and compact, the CCAW (Copper Clad Aluminium Wire) voice coils wound on double layer provide very high efficiency and neat, dynamic sound.
  • The Radial Venting System ensures high thermal capability, power handling and reliability.
  • Cotton-fibre pressed paper cone with Light Damping treatment.
  • Orientable High Frequency Tuning: high range controlled dispersion for the best performance in the listening point.
  • Tetolon dome Neodymium tweeter.
  • On-wire dedicated crossover network, for best performance at crossover frequencies.
Specifications
Woofer Size165 mm
Tweeter Size25 mm
Woofer Power Handling - Peak200 W
Woofer Power Handling - Continuous100 W
Woofer Impedance4 Ohm
Woofer Frequency Response50 ÷ 22k
Integrated Crossover3.5 kHz @ 6/12 dB/Oct.
Woofer Magnet Size90 x 40 x 15
Tweeter Magnet Size25 x 3,5
Woofer Voice Coil Diameter30 mm
Xmax3 mm
ELECTRIC-ACOUSTIC SPECS
D130 mm
Re3.5 Ohm
Fs68 Hz
LE standard0.59
Vas8.2 l
Mms16.1 g
Cms0.34
Bl5.5
Qts0.74
Qes0,82
Qms7.84
Woofer Spl91 dB
General
Weight1.3 kg
Dimensions
Dimension A167 mm
Dimension B146 mm
Dimension C75.5 mm
Dimension D69 mm
Dimension E156 mm
Dimension F88
Dimension G30 mm
Dimension H193 mm
