Features
- 7,000 ANSI Lumens Brightness
- Laser 4K UHD & 3M:1 CR
- from 40" to 300" Screen Size
- Edge Blending technology
- Auto Screen Adjustment
Smart Digital Signage for Expansive Viewing
Picture Quality
7,000 ANSI Lumens 4K UHD (3840 x 2160)
Easy Installation
Edge Blending Auto Screen Adjustment
Efficient Management
SuperSign LG Connected Care
All-around Projector for Versatile Fields
Laser 4K UHD & 3M:1 CR
Exceptional Picture Quality
With 8.3 mega pixels utilizing 4K UHD (3840 x 2160) resolution, LG ProBeam delivers precisive details from 40-inch up to the 300-inch screen. With 3M:1 contrast ratio, it can express deep darkness and brightness.
7,000 ANSI Lumens Brightness
Accurate Color Even in Bright Ambient
Thanks to the 7,000 ANSI Lumens brightness, LG BU70QGA can produce clear picture quality even in bright indoor environments such as building lobbies.
Edge Blending
Seamless Panoramic View
By supporting Edge Blending technology which controls the luminance of the area where the projected light overlaps, it can provide the seamless connection without resulting in a higher luminance when two or more projectors must be used simultaneously.
Designed for Many-sided Installation
LG BU70QGA can adjust the screen distortion even in situations where projector installation space may be limited, or an existing bracket has already been installed.
Auto Screen Adjustment
Simply Adjust Screen Distortion
With an Auto Screen Adjustment function, it can automatically correct the screen using the appropriate technology according to the installation status.
4/9/15/25 Point Warping
Lens Shift (+60/-33%), H (28%)
1.6x Zoom
Screen Rotation
Rotate the Screen as You Want
As supporting Screen Rotation you can position the projector anywhere you want, or rotate the screen without physically changing the projector's position.
SuperSign
The Easy Way to Manage and Maintenance
By supporting signage-optimized functions, various solutions such as content distribution and remote management of installed projectors are provided.
LG SuperSign CMS
It is a content management software solution optimized for LG webOS signage. It supports multiple displays and accounts, so multiple users can easily access the server from PC or mobile, then manages content creation and editing, scheduling, and distribution.
LG SuperSign Control+
SuperSign Control+ is a remote control and monitoring software solution. It focuses on large scale deployment. Multiple administrators can access the SuperSign Control+ server via the network to monitor the status of connected displays in real-time, control them, and adjust their setting values.
LG ConnectedCare
It is a cloud service solution that can remotely manage the operating status of installed projectors, guaranteeing stable business operations by providing remote monitoring and fault diagnosis.
1. Real-time Monitoring
2. B2B Call Center : Request Assistance
3. SE Preparation : Mobile Diagnosis
4. Site Visit by Service Engineer
5. Troubleshooting
6. Issue Resolved
| Added Features | |
|---|---|
| Quick(Instant) Power on/off | Yes (on 12 Sec off 2 Sec) |
| HDCP | HDCP2.2 |
| Digital Keystone Correction | Warping (4/9/15/25/HV)(Auto) |
| TruMotion | Yes |
| DICOM | Yes |
| HDR | Yes |
| MAIN FEATURES | |
| Eco Function - HDD Eco Mode | Yes |
| Eco Function - Automatic Standby / Auto Power Off | Yes (On / Off) |
| Eco Function - Time Power On/Off (On Time / Off Time) | Yes |
| Eco Function - Sleep Timer | Yes (Min/Mid/Max) |
| Eco Function - Energy Saving Mode | Yes |
| Setting Guide | Yes (Bean Bird) |
| USB Host (Movie, Music, Photo) | Yes (Except for Music) |
| PROJECTION SYSTEM | |
| Projection Lens - Focus (Auto / Manual) | Auto |
| Uniformorty(JBMMA 9point) | 85% |
| Noise (typical) - Energy Saving Off (Max) | 31 dB(A) |
| Noise (typical) - Energy Saving Med. | 33 dB(A) |
| Noise (typical) - Energy Saving Min. (Bright) | 35 dB(A) |
| Contrast Ratio (Full On Full Off) | 3,000,000:1 ↑ |
| Brightness (ANSI Lumen) | 7000 |
| Native Resolution | 4K UHD (3840 x 2160) |
| MAIN FEATURES | |
| Plug & Play(RGB/DVI/HDMI Auto Source Detection) | Yes |
| LG Sound Sync(with Sound Bar) | Yes |
| Bluetooth Sound out | Yes |
| Contents Sharing (with DLNA supporting device) | Yes |
| Screen Share (Wireless Mirroring with MiraCast supporting device) | Yes |
| Platform (OS, UI) | Signage webOS ECO |
| INPUT/OUTPUT TERMINALS | |
| mic in | Yes (Phone jack) |
| USB Type-A | 2 (USB2.0) |
| HDBaseT | 1 |
| HDM(out) | 1 |
| HDMI(in) | 3 |
| RJ45 | 1 |
| IP control | Yes |
| RS-232C(out) | 1 |
| RS-232C(in) | 1 |
| Audio out | Yes (Phone jack) |
| General Specification | |
| Input Signal Compatibility - HDBaseT | Yes |
| Input Signal Compatibility - Digital(HDMI) | Up to 4K (4096x2160)(60Hz, 50Hz, 24Hz) |
| Operation Temperature | 0 ~ 40℃ |
| Power Supply | 100V |
| Gross size (mm) (W x D x H) | 774 x 473x 265 |
| Gross Weight (kg or g) | 20.5KG |
| Power Consumption (Max.) | 500W |
| Stand-by Power | 0.5W |
| Net Weight (kg or g) | 17.8kg |
| Net Size (mm) (W x D x H) | 570x360x160 |
| Sound - Clear Voice | Yes (Clear Voice lll) |
| Sound - Output | 10W (5W+5W) |
| Aspect Ratio Control | Full / Original |
| PROJECTION SYSTEM | |
| Light source - Life High Brightness | 20,000 Hrs |
| Light source - Type | Laser (LD + P/W) |
| Projection Offset | 110% |
| Lens Shift | ( Horiz ± 28% / Vert +60%,-33% ) (Auto) |
| Projection Image - Throw Ratio | 1.53 ~ 2.45 |
| Projection Image - Standard (lens to wall) | Wide 3395 /Tele 5470 (100inch) |
| Projection Lens - Zoom | 1.6x Auto |
| Projection Image - Screen Size | 40" ~ 300" |
| Accessory | |
| Conformances(Regulation) | FCC/ETL/CE/CB/CCC/PSE/BIS |
| Remote control (Battery included) - Normal | Yes |
| Cable - Power cord | 1 |
| Cable - RS232C cable(D-sub to phone) | 1 |
| Warranty Card | Yes |
| Quick User Guide (Quick Set-up Guide) | Yes |
| Manual (Full or Simple Book) | Yes |
| Design | |
| Ceiling mount hole (for bracket) | Yes |
| Leg-Stand | Yes (4 Leg) |
| Kensington Lock | Yes |
| Added Features | |
| Expert controlvADJ | Yes |
| Brilliant Color™ (Overlap Duty) | Yes |
| Gamma Correction | Yes |
| Noise Reduction | Yes |
| HDMI ARC(Audio Return Channel) | Yes |
| HDMI simplink(CEC) | Yes |
| Design | |
| Cabinet Color | Clay charcoal |
| Local Key | Tact (9key) |
| Added Features | |
| Color Temperature Adjustment | Yes |
| Black Level Control | Yes |
| 360 degree Installation | Yes |
| One Quick Share | Yes |
| Daisy Chain | Yes |
| 24/7 Operation | Yes |
| Crestron RoomView™ | Yes |
| PBP | Yes |
| PIP | Yes |
| Tile Mode | Yes (9) |
| Auto Screen Adjustment | Yes (Camera Sensor+ ToF Sensor) |
| Edge Blending | Yes |
| Image Flip | Yes (Horizontal/Vertical) |
| Blank | Yes |
| Background Image | Yes |
| Built-in Memory (for Storage) | Yes (about 9G) |
